Technical highlights:
Automatic bag width adjustment
Mechanical transmission technology
Operating and using the touch screen makes maintenance and inspection easier
It can be used in various automatic filling devices
Automatic lubricating oil system
Vacuum chamber for aviation engraving and milling

II. Product Overview
Scope of application: Bean products, meat products, egg products, pickled vegetables, ready-to-eat meals, braised products, and other snack foods

III. Product Performance
(1) The bag-feeding fully automatic vacuum packaging machine consists of two rotary integrated machines (a filling system and a vacuum system respectively). The vacuum system features continuous rotary motion, with no inertia and no impact force.
(2) Quickly change the packaging bag specifications, and automatically adjust to different bag specifications with one click.
(3) Meet the hygiene standards for food processing machinery. The parts of the machine that come into contact with materials or packaging bags are made of 304 stainless steel or other materials that meet food hygiene requirements, ensuring the hygiene and safety of food.
(4) Easy to operate: It adopts the Siemens PLC and POD (touch screen) electrical control system, featuring a user-friendly interface and easy operation. Bags without material, seals, or fillers can be recycled, preventing waste.
(5) Sealing temperature detection function: If the heating plate is damaged, an automatic alarm will be triggered on the touch screen.
(6) The sealing method employs instantaneous heating and water cooling to achieve a smoother and more aesthetically pleasing seal.
(7) The vacuum chamber is crafted from aviation-grade aluminum using computer-controlled machining, ensuring resistance to hardening and deformation, as well as excellent sealing and durability.

Technical Parameter
